Case Mod Friday: Loramentum

Project Name: Loramentum

Case Mod Friday: Loramentum

About this mod / project:
Loramentum (Latin for frame, strap or… thong) is a watercooled wall mounted rig, but with a twist. I wanted to be able to take this build to LAN events relatively simply. The main framework is constructed from machined acrylic, with the reservoir and a fair bit of the tubing integrated into the chassis itself. The RAM and waterblock were gold plated to fit with the theme, along with full custom cabling, the motherboard is the only unmodded component! The whole build fits neatly into a flight case for easier transport too, bit heavy though…

Photos:

900x900px-LL-3ec35926_54wUOi 900x900px-LL-3f293d45_1 900x900px-LL-4a434e7a_4mfn8y 900x900px-LL-8ad7ef26_s3Cw6e 900x900px-LL-11afdd21_dizKTJ 900x900px-LL-77c06348_xHEiFD 900x900px-LL-88c7240b_6KqgBr 900x900px-LL-290c341b_PETNIX 900x900px-LL-921537a2_MaRaRE 900x900px-LL-59238169_kFWK6Q 900x900px-LL-a90a967f_PD7MQb 900x900px-LL-ad1d6c77_1xN3lA 900x900px-LL-b0a364f7_VKKAi9 900x900px-LL-e3566ea7_CBVahc 900x900px-LL-e659880f_sLCFij 900x900px-LL-ebeca3f2_0fslpM 900x900px-LL-3bb8ec42_5ob2ma

Hardware:
CPU: i7 4770k
Mobo: Asus Z87 Pro-I
RAM: 16GB Corsair Dominator Platinum 1866MHz
GPU: Asus R9 290
PSU: Corsair RM650
SSD: Samsung Evo

Cooling:
– EK ASUS R9 290 Full cover waterblock
– EK Radiator
– Custom reservoir built into chassis
– EK CPU waterblock
– EK D5 pump

Custom Mods:
– Custom wall-mounted chassis
– Tubing built into the chassis itself
– Custom sleeving on the PSU
– Custom paint on the memory, PSU fan, SSD and more
– RAM and GPU waterblock gold-plated
– Made to fit into a carrying case for LAN parties

Build Log: Overclock.net

Builder: MakiRole
