Case Mod Friday: Lutfi’s AMS

Project Name: Lutfi’s AMS

Tell us a little about your case / case mod?
Primarily my workstation rig that I had the pleasure of building from the ground up but thought of going the extra mile by venturing into full-on custom watercooling. Getting the most out of an already aging machine where the temps were what was holding me back on overclocks. The hidden intention for this build was to go watercooling without the over-the-top blingy approach – instead a subtle machine sitting quietly next to my workstation.

Photos:
[nggallery id=51]

Hardware:
– Intel Q9550 E0 @ 3.4Ghz on 1.13v Vcore
– Asus Rampage Extreme w/SupremeFX X-Fi
– Mushkin Redline Ridgeback 996982 8GB 1600MHz kit
– Aquacomputer Airplex Modularity System 360 copper w/ D5 pump/res unit w/ vertical res attachment
– XSPC Raystorm Copper Edition
– Watercool Heatkiller NSB3.0 copper on Fusion system
– 1/2″ OD DangerDen Perfect seal barbs
– Lamptron FC5 v2
– Scythe GT AP-15 in push
– 140mm bitfenix Spectre Pro
– 120mm Bitfenix Spectre
– Noiseblocker M12-P
– Scythe Jyuni
– 320GB WD Blue 16MB – OS Drive
– 500GB WD Caviar Green 32MB in Raid 0
– 500GB WD Blue 32MB
– Lite-on DVD+/-RW
– XFX Radeon 6870 Black Edition 1GB DDR5
– Thermaltake Spedo
– Thermaltake Toughpower Grand 750W

List of Custom Modifications
– Fusion system washer mod
– Replaced existing thermal tape with Fujipoly extreme
– Minor case modification for tubing runs
– Swapped out POWER and HDD LED and modded acrylic for diffused lighting
– Custom anodized black M3 Screws for AMS rad
– SupremeFX daughtercard screw mod

Builder: Lutfi Jahangir

Worklog: http://www.tomshardware.com/forum/273453-29-lutfi-build-officially-first-build

Do you want your mod to be featured on Case Mod Friday? Submit it here: http://thinkcomputers.wpengine.com/case-mod-friday-submission/
