Lian Li PC-TU200 Case Review

I have to say I am a huge fan of small form factor (SFF) cases.  Not only because they are small but I am amazed at all of the features they can pack into such a small case.  Today’s case is no exception.  It fits Mini-ITX and Mini-DTX motherboards, has internal USB 3.0 and eSATA compatibility, a large 140mm intake fan, room for both 3.5-inch and 2.5-inch hard drives, a really cool side panel release system and even a handle on top for easy transportation.  The case I’m talking about is the PC-TU200 from Lian Li.  Read on as we have the review.

Special thanks to Lian Li for providing us with the PC-TU200 Case to review.

Model: PC-TU200
Case Type: Mini Tower Chassis
Dimensions: (W) 220mm x (H) 320mm x (D) 360mm
Front bezel Material: Aluminum
Color: Black / Silver
Side Panel: Aluminum
Body Material: Aluminum
Net Weight: 3.15KG
5.25″ drive bay (External): 1
3.5″ drive bay (External): None
HDD bay: 3.5-Inch HDD x4 / 2.5-Inch HDD x2 (One used in the 3.5-inch bay)
Expansion Slot: 2
Motherboard: Mini-ITX / Mini-DTX
System Fan (Front): 140mm fan x1
System Fan (Top): None
System Fan (Rear): None
I/O Ports: e-SATA / USB3.0 x 2 / HD Audio
Maximum Compatibility
– VGA Card length: 300mm
– PSU length: 140mm
– CPU cooler height: 80mm

The PC-TU200 comes in a box that is not much larger than the case itself.  On the front there is a picture of the case and an overview of some of the features.  On the side you have the list of specifications.

Lian Li PC-TU200 Case Lian Li PC-TU200 Case

To give you a good idea of how the PC-TU200 comes and a brief overview check out our unboxing video below.
