A picture of ASRock’s Radeon RX 5600 XT Phantom Gaming OC Graphics Card has been leaked to the web, being one of the first shots we’ve seen of the card. Looking at the card it looks like it features a shorter PCB, but makes use of a longer triple-fan cooling solution. The cooling solution has a large aluminum fin stack that is ventilated by three 80 mm cooling fans. As far as power there is a single 8-pin PCI-Express power connector, which indicates much lower power draw than the RX 5700 series. The box also confirms 6 GB of GDDR6 memory and factory-overclocked speeds, which are 1560 MHz gaming according to VideoCardz.
The RX 5600 XT is designed to compete with NVIDIA’s GeForce GTX 1660 Ti. It has 2304 stream processors, 144 TMUs, and possibly 48 ROPs. The 6GB of GDDR6 memory runs at 12 Gbps across a 192-bit memory interface. By all accounts the RX 5600 XT is based on the 7nm Navi 10 silicon, with a quarter of its memory interface disabled. AMD is expected to reveal the card at CES 2020.
